The new columns of the C400-EN range feature loudspeakers with a broad response range and high-efficiency tweeters enabling perfect intelligibility of speech and accurate reproduction of music.These speaker units have been developed specifically for use in emergency and evacuation systems (VES) and each has its own ceramic terminal strip and thermal fuse. These ensure the protection of the line connecting the loudspeakers if a fire puts one or more of the speaker units connected to it out of use. This speaker units are fitted with fire proofcable according to UNI 9795 2010 (length 80 cm). These columns can be turned in any direction thanks to the S4-B swivel joint included in the supply.

The new columns of the C400-EN range feature loudspeakers with a broad response range and high-efficiency tweeters enabling perfect intelligibility of speech and accurate reproduction of music.These speaker units have been developed specifically for use in emergency and evacuation systems (VES) and each has its own ceramic terminal strip and thermal fuse. These ensure the protection of the line connecting the loudspeakers if a fire puts one or more of the speaker units connected to it out of use. This speaker units are fitted with fire proofcable according to UNI 9795 2010 (length 80 cm). These columns can be turned in any direction thanks to the S4-B swivel joint included in the supply.

Models C44/12-EN were designed specifically for use in emergency and evacuation systems (VES). Each unit has a ceramic terminal block and a thermal fuse. They are certified for compliance with EN 54-24:2008. The metal box for flush-mounting makes this operation easy and quick, with spring-mounted hooks (included in the supply).

The ideal application for speaker units of the C44/6-TB speaker units is in hospitals, hotels, offices, schools, shops or anywhere where flush-mounting and a discreet and elegant appearance are required. Each unit is made of self-extinguishing plastic material UL94-VO with a metal front grille and a line transformer. The (optional) AC91 box for flush-mounting makes wall-mounting easy and quick.

The C46/6-EN and C46/10-EN sound projectors have as the main feature an excellent reproduction of sound and a compact size.
The wide-band loudspeaker is treated to withstand moisture and suitable for both indoors and outdoors provided the unit is sheltered from direct rain.
This speaker unit has been developed specifically for use in emergency and evacuation systems (VES) and has its own ceramic terminal strip and thermal fuse. These ensure the protection of the line connecting the loudspeakers if a fire puts one or more of the speaker units connected to it out of use.

Column-type speaker unit made of pale grey extruded aluminium
with hermetically sealed ends made of shockproof material.
Made up of 4 wide-band loudspeakers and transformer for 60 W
constant-voltage lines (attenuation is possible).
A swivelling support, running along the rear guides of the speaker
unit, makes it easy to fix it to a wall.

Particularly suitable for use outdoors, even in bad weather
conditions.

The speaker units for ceiling-mounting of the C51 range consist of an ABS structure with a RAL 9016 white-painted grille. They feature a compact size and an excellent acoustic performance. Each unit has handy tough spring-type hooks that make it easy to fasten securely to a false ceiling. A transformer for connection to a 100V constant-voltage line is included in the supply, with selectable power-output steps.

The C51HF/20-EN ceiling speaker unit features a loudspeaker with a 5.25” cone and a 1” tweeter, self-extinguishing
ABS body and metal fire dome and grille. Suitable for flush-mounted installation in false-ceilings, it is equipped
with a protected integrated thermal fuse, a 100V transformer for connection via terminals to constant voltage
lines and a rotary switch that allows you to easily adjust the output power. Low impedance connection (8 Ω) is
also available. The C51HF/20-EN model provides excellent sound performance and speech intelligibility, as well
as powerful music reproduction. It is ideal for installation in large facilities such as schools, hotels, airports and
conference rooms.

The C51HF/30-EN ceiling speaker unit features a loudspeaker with a 6.5” cone and a 1” tweeter, self-extinguishing
ABS body and metal fire dome and grille. Suitable for flush-mounted installation in false-ceilings, it is equipped
with a protected integrated thermal fuse, a 100V transformer for connection via terminals to constant voltage
lines and a rotary switch that allows you to easily adjust the output power. Low impedance connection (8 Ω) is
also available. The C51HF/30-EN model provides excellent sound performance and speech intelligibility, as well
as powerful music reproduction. It is ideal for installation in large facilities such as schools, hotels, airports and
conference rooms.

The C51HF/40-EN ceiling speaker unit features a loudspeaker with a 8” cone and a 1” tweeter, self-extinguishing
ABS body and metal fire dome and grille. Suitable for flush-mounted installation in false-ceilings, it is equipped
with a protected integrated thermal fuse, a 100V transformer for connection via terminals to constant voltage
lines and a rotary switch that allows you to easily adjust the output power. Low impedance connection (8 Ω) is
also available. The C51HF/40-EN model provides excellent sound performance and speech intelligibility, as well
as powerful music reproduction. It is ideal for installation in large facilities such as schools, hotels, airports and
conference rooms.

The speaker units for flush-mounting of the C52 range are designed specifically for quick installation in false-ceiling panels. They are made of moulded sheet metal with an extremely thin front part. They are ideal for reproduction of both speech and music and are suitable for installation in conference halls, shops and offices. They have strong and handy spring-type hooks making them easy to secure quickly to a false ceiling. Each loudspeaker has a transformer for connection to a 100 V constant-voltage line. The various selectable power steps provide flexibility of installation and the ability to adapt to the acoustic characteristics of different types of room.

The speaker units for flush-mounting of the C52 range are designed specifically for quick installation in false-ceiling panels. They are made of moulded sheet metal with an extremely thin front part. They are ideal for reproduction of both speech and music and are suitable for installation in conference halls, shops and offices. They have strong and handy spring-type hooks making them easy to secure quickly to a false ceiling. Each loudspeaker has a transformer for connection to a 100 V constant-voltage line. The various selectable power steps provide flexibility of installation and the ability to adapt to the acoustic characteristics of different types of room.

The units for ceiling mounting of the C53 range, designed for easy and quick installation in a false ceiling by means of handy spring-type hooks, are made of moulded sheet metal with an extremely thin front part. Their size and the high quality of the loudspeaker used make it ideal for the reproduction of speech and music and suitable for installation in conference halls and medium-to-large shops and offices. A transformer for connection to a 100V constant-voltage line with selectable power-output steps is included in the supply.

otection cap-adjustable power 10/5/2,5 W

sformer-adjustable power 6/3/1,5/0,75 W

White, with 100V transf., tap 6/3/1,5W
Ø 220 mm

peaker, white, in ABS, with 4,5 m cable

r-Adjustable power 30/15/7,5/3,8 W-8 ohm
